SMA-J - Samtec 50 Ohm SMA Jack, Edge Mount SamΩ (SMAEM)

From: £1.487

Part No.	Stock Qty	Price Breaks					Qty
SMA-J-P-H-ST-EM1 3D CAD	628 in stock	1+: £2.46	50+: £2.39	100+: £2.26	View all prices		When ordering more than in stock, please contact us to confirm delivery time. There was a problem adding this item to the cart. Please contact us on the above number to order.
SMA-J-P-H-ST-EM3 3D CAD	Standard delivery 4 - 6 working days *	1+: £6.08	25+: £5.91	50+: £5.60	View all prices		When ordering more than in stock, please contact us to confirm delivery time. There was a problem adding this item to the cart. Please contact us on the above number to order.

Qty.	Unit Price	Ext. Price

* Delivery times are from point of order and subject to material availability.

* When ordering more than in stock, please contact us to confirm delivery time.

* Need help or more stock/delivery information or volume pricing - Please contact us

* Delivery times are from point of order and subject to material availability.

* When ordering more than in stock, please contact us to confirm delivery time

* Need help or more stock/delivery information or volume pricing - Please contact us

Contact Material: BeCu

Shell Material: Brass

Insulator Material: PTFE (-PN)

Operating Temp Range: -65°C to +125°C

Contact Resistance: Center Contact: 6mΩ max

Outer Contact: 2mΩ max

Insulator Resistance: 5,000 MΩ

Impedance: 50Ω

Dielectric Withstanding Voltage: 1,000 Vrms

Frequency Range: 0~20 GHz

(Cable dependent)

Working Voltage: 335V

Lead–Free Solderable: Yes

Samtec SMA 50 Ohm RF Connectors and Components, Subminiature interconnects with screw-type coupling.

With performance up to 6 GHz available in a wide variety of cable assemblies, orientations and PCB terminations.
