Part No. | Stock Qty | 1+ | 100+ | 500+ | 1000+ | Qty |
---|---|---|---|---|---|---|
3048-02FN
2x1 Positions |
294 in stock | £0.98 | £0.81 | £0.66 | £0.54 | |
3048-04FN
2x2 Positions |
291 in stock | £1.11 | £0.92 | £0.74 | £0.62 | |
3048-06FN
2x3 Positions |
300 in stock | £1.31 | £1.10 | £0.88 | £0.73 | |
3048-08FN
2x4 Positions |
1196 in stock | £1.56 | £1.30 | £1.03 | £0.87 | |
3048-10FN
2x5 Positions |
300 in stock | £1.74 | £1.44 | £1.16 | £0.97 | |
3048-12FN
2x6 Positions |
200 in stock | £1.91 | £1.59 | £1.29 | £1.07 | |
3048-14FN
2x7 Positions |
200 in stock | £2.13 | £1.78 | £1.42 | £1.19 | |
3048-16FN
2x8 Positions |
200 in stock | £2.31 | £1.92 | £1.53 | £1.29 | |
3048-18FN
2x9 Positions |
198 in stock | £2.56 | £2.13 | £1.70 | £1.42 | |
3048-20FN
2x10 Positions |
195 in stock | £2.80 | £2.33 | £1.87 | £1.56 | |
3048-22FN
2x11 Positions |
200 in stock | £2.96 | £2.46 | £1.97 | £1.63 | |
3048-24FN
2x12 Positions |
197 in stock | £3.11 | £2.60 | £2.09 | £1.73 |
* Delivery times are from point of order and subject to material availability.
* When ordering more than in stock, please contact us to confirm pricing and delivery time
* Need help or more stock/delivery information or volume pricing - Please contact us
Insulator Material: Black LCP UL94V (UL E41938)
Contact & Tab Material: Brass
Contact & Tab Plating: Tin
Current Rating: 5 Amps(20 & 22awg), 4 Amps(24awg) (vs Wire Size - awg) 3 Amps(26awg), 2 Amps(22awg), 1Amp (30awg)
Rated Voltage: 250V AC(rms) or DC
DWV: 1500V AC for 1 minute
Contact Resistance: 10mΩ Max.
Operating Temperature: -25°C to +85°C
Tolerance: ±0.25mm
Glow-Wire Flammability: (GWFI) IEC 60695-2-12
Glow-Wire Ignition: (GWIT) IEC 60695-2-13
